| PartZenbakia | TM101DDHG03 |
| Marka | Tianma |
| Tamaina | 10.1 |
| Aplikazio | IA |
| Ebazpena | 1024×600 |
| Konposizioa | LCM |
| Distira | 300 |
| CR | 800:1 |
| Koloreak | 262K/16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | TIANMA |
| panel eredua | TM101DDHG03 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 10.1 inch |
| ebazpena | 1024(RGB)×600 , WSVGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 222.72×125.28 mm |
| eskema | 233×137×3.2 mm |
| azalera | Antiglare, Hard coating (3H) |
| distira | 300 cd/m² (Typ.) |
| kontraste-erlazioa | 800:1 (Typ.) |
| bistaratzeko koloreak | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193150% |
| erantzun denbora | 7/9 (Typ.)(Tr/Td) |
| ikuspegi angelua | 80/80/75/80 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 3S10PWLEDEmbedded (LED Driver) |
| seinale interfazea | LVDS (1 ch, 6/8-bit), 41 pins |
| sarrerako tentsioa | 3.3/11.02/21.14/-7V (Typ.)(VDD/AVDD/VGH/VGL) |
| aplikazio | IA |
