| PartZenbakia | TM101DDHG01 |
| Marka | Tianma |
| Tamaina | 10.1 |
| Aplikazio | CNS |
| Ebazpena | 1024×600 |
| Konposizioa | LCM |
| Distira | 450 |
| CR | 800:1 |
| Koloreak | 262K/16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | TIANMA |
| panel eredua | TM101DDHG01 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 10.1 inch |
| ebazpena | 1024(RGB)×600 , WSVGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 222.72×125.28 mm |
| eskema | 235×143×5.1 mm |
| azalera | Antiglare, Hard coating (3H) |
| distira | 450 cd/m² (Typ.) |
| kontraste-erlazioa | 800:1 (Typ.) |
| bistaratzeko koloreak | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193147% |
| erantzun denbora | 7/9 (Typ.)(Tr/Td) |
| ikuspegi angelua | 80/80/75/80 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | WLEDEmbedded (LED Driver) |
| seinale interfazea | LVDS (1 ch, 6/8-bit), 40 pins |
| sarrerako tentsioa | 3.3V (Typ.) |
| aplikazio | CNS |
| AM-1024600L3TMQW-T05H | AMPIRE | 10.1 | 1024×600 |
| CLAA101FP05 | CPT | 10.1 | 1920×1200 |
| CLAA101WH13LE | CPT | 10.1 | 1280×800 |
| EJ101IA-02A | Innolux | 10.1 | 1280×800 |
| HSD101PUW1-A00 | HannStar | 10.1 | 1920×1200 |
| LP101WH4-SLAF | LG Display | 10.1 | 1366×768 |
| M101GWN9 R2 | IVO | 10.1 | 1024×600 |
| TM101DDHG01 | Tianma | 10.1 | 1024×600 |
| TM101DDHG03 | Tianma | 10.1 | 1024×600 |
| TM101JDHP01 | Tianma | 10.1 | 1280×800 |
| AM-800480STMQW-00 | AMPIRE | 7.0 | 800×480 |
| C080VW03 V0 | AUO | 8.0 | 800×480 |
| CLAA061LA0ACW | CPT | 6.1 | 800×480 |
| CLAA070LC05CW | CPT | 7.0 | 800×480 |
| CLAA070NJ05CW | CPT | 7.0 | 1024×600 |
| CLAA070NJ07CW | CPT | 7.0 | 1024×600 |
| HSD070IFW1-A00 | HannStar | 7.0 | 1024×600 |
| LA080WV1-TD01 | LG Display | 8.0 | 800×480 |
| LQ101K5DZ01 | SHARP | 10.1 | 1280×422 |
| LS800JT9001 | Innolux | 8.0 | 800×600 |
