| PartZenbakia | L5S30883P00 |
| Marka | SANYO |
| Tamaina | 4.5 |
| Aplikazio | CNS |
| Ebazpena | 480×240 |
| Konposizioa | LCM |
| Distira | 400 |
| CR | 300:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | TTL |
| panel marka | SANYO |
| panel eredua | L5S30883P00 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 4.5 inch |
| ebazpena | 480(RGB)×240 , WQVGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 99.36×56.04 mm |
| eskema | 112.7×70.2 mm |
| azalera | Glare (Haze 0%) |
| distira | 400 cd/m² (Typ.) |
| kontraste-erlazioa | 300:1 (Typ.) |
| bistaratzeko koloreak | 262K (6-bit) |
| erantzun denbora | 10/20 (Typ.)(Tr/Td) |
| ikuspegi angelua | 55/55/45/55 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | WLEDEmbedded (LED Driver) |
| seinale interfazea | Parallel RGB (1 ch, 6-bit), 40 pins |
| sarrerako tentsioa | 3.3V (Typ.) |
| rohs: | |
| aplikazio | CNS |
