| PartZenbakia | C070FW02 V2 |
| Marka | AUO |
| Tamaina | 7.0 |
| Aplikazio | CNS |
| Ebazpena | 480×234 |
| Konposizioa | LCM |
| Distira | 410 |
| CR | 300:1 |
| Koloreak | |
| Atzeko argia | CCFL |
| Interfazea | Analog |
| panel marka | AUO |
| panel eredua | C070FW02 V2 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 7.0 inch |
| ebazpena | 480(RGB)×234 |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 154.08×86.58 mm |
| eskema | 164.9×100 mm |
| azalera | Antiglare (Haze 25%) |
| distira | 410 cd/m² (Typ.) |
| kontraste-erlazioa | 300:1 (Typ.) |
| bistaratzeko koloreak | |
| erantzun denbora | 12/18 (Typ.)(Tr/Td) |
| ikuspegi angelua | 60/60/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| lanpara mota | 1 pcsCCFLWithout Driver |
| seinale interfazea | TFT Specific Analog RGB, 30 pins |
| sarrerako tentsioa | 5/5/15/-10V (Typ.)(VCC/AVDD/VGH/VGL) |
| rohs: | |
| aplikazio | CNS |
| 70WVW2A | SII | 7.0 | 800×480 |
| AM-800480STMQW-W0 | AMPIRE | 7.0 | 800×480 |
| AT070TN82 V.1 | Innolux | 7.0 | 800×480 |
| C070FW01 V0 | AUO | 7.0 | 480×234 |
| C070FW02 V0 | AUO | 7.0 | 480×234 |
| C070FW02 V2 | AUO | 7.0 | 480×234 |
| C070FW03 V0 | AUO | 7.0 | 480×234 |
| LQ070Y3DG3A | SHARP | 7.0 | 800×480 |
| P070BAG-CM1 | Innolux | 7.0 | 1024×600 |
| PM070WX1 | E Ink | 7.0 | 800×480 |
| AV128HDM-NW0 | BOE | 12.8 | 1280×720 |
| C065GW02 V1 | AUO | 6.5 | 400×234 |
| CLAA080LJ01CW | CPT | 8.0 | 800×480 |
| DLC0700DDG-4 | Other | 7.0 | 800×480 |
| G080Y1-T01 | Innolux | 8.0 | 800×480 |
| LA060N01-SD01 | LG Display | 6.0 | 720×272 |
| LB040Q02-TD01 | LG Display | 4.0 | 320×240 |
| LQ070Y5DG36 | SHARP | 7.0 | 800×480 |
| TJ123NP01AA | TPO | 12.3 | 1280×480 |
| TJ123NP01CA | Innolux | 12.3 | 1280×480 |
