| PartZenbakia | TM045XDZP08 |
| Marka | Tianma |
| Tamaina | 4.5 |
| Aplikazio | MPH |
| Ebazpena | 540×960 |
| Konposizioa | LCM |
| Distira | 350 |
| CR | 800:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | MIPI |
| panel marka | TIANMA |
| panel eredua | TM045XDZP08 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 4.5 inch |
| ebazpena | 540(RGB)×960 , qHD |
| bistaratzeko modua | IPS, Normally Black, Transmissive |
| eremu aktiboa | 55.485×98.64 mm |
| eskema | 60.71×109.1 mm |
| azalera | |
| distira | 350 cd/m² (Typ.) |
| kontraste-erlazioa | 800:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (8-bit), CIE193170% |
| erantzun denbora | 25 (Typ.)(Tr+Td) |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 10S1PWLEDWithout Driver |
| seinale interfazea | MIPI (2 data lanes), 25 pins |
| sarrerako tentsioa | 1.8/2.8V (Typ.)(IOVCC/VDD) |
| aplikazio | MPH |
| ACX425AKM | SONY | 3.7 | 480×800 |
| BT043NHME601 | BOE | 4.3 | 360×600 |
| CLAF055LA41 TXX | CPT | 5.5 | 540×960 |
| CLAN050LL31 1XG | CPT | 5.0 | 480×800 |
| H546DAN01.2 | AUO | 5.5 | 1080×1920 |
| HSD050FMW2-D00 | HannStar | 5.0 | 540×960 |
| LH350H01-FD01 | LG Display | 3.5 | 320×480 |
| LS026Q7UX01 | SHARP | 2.6 | 320×240 |
| LS037V7DD06R | SHARP | 3.7 | 480×640 |
| LTM030DH60 | TOSHIBA | 3.0 | 240×427 |
