| PartZenbakia | AV080WSM-NW0 |
| Marka | BOE |
| Tamaina | 8.0 |
| Aplikazio | CNS |
| Ebazpena | 1024×600 |
| Konposizioa | LCM |
| Distira | 600 |
| CR | 800:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | BOE |
| panel eredua | AV080WSM-NW0 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 8.0 inch |
| ebazpena | 1024(RGB)×600 , WSVGA |
| bistaratzeko modua | ADS, Normally Black, Transmissive |
| eremu aktiboa | 176.64×99.36 mm |
| eskema | 192.8×116.9 mm |
| azalera | |
| distira | 600 cd/m² (Typ.) |
| kontraste-erlazioa | 800:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (6-bit + Hi-FRC), CIE193150% |
| erantzun denbora | 25 (Typ.)(Tr+Td) |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 3S10PWLEDWithout Driver |
| seinale interfazea | LVDS (1 ch, 8-bit), 40 pins |
| sarrerako tentsioa | 3.3/11.5/18.0/-10.0V (Typ.)(VDD/AVDD/VGH/VGL) |
| aplikazio | CNS |
| CLAA061LA0ACW | CPT | 6.1 | 800×480 |
| G070Y2-T02 | Innolux | 7.0 | 800×480 |
| L5F30818P04 | SONY | 6.5 | 800×480 |
| LA080WV1-TD01 | LG Display | 8.0 | 800×480 |
| LB058WQ1-SD03 | LG Display | 5.8 | 400×240 |
| LQ070T5GC01 | SHARP | 7.0 | |
| LQ080Y5DZ30A | SHARP | 8.0 | 800×480 |
| LTA070B792F | TOSHIBA | 7.0 | 800×480 |
| ND068-101A1 | 6.8 | 1280×480 | |
| TM062RDZG10 | Tianma | 6.2 | 800×480 |
