| PartZenbakia | BP096WX7-100 |
| Marka | BOE |
| Tamaina | 9.6 |
| Aplikazio | PAD |
| Ebazpena | 800×1280 |
| Konposizioa | CELL |
| Distira | 0 |
| CR | 800:1 |
| Koloreak | 16.7M |
| Atzeko argia | No B/L |
| Interfazea | MIPI |
| panel marka | BOE |
| panel eredua | BP096WX7-100 |
| panel mota | a-Si TFT-LCD , CELL |
| panelaren tamaina | 9.6 inch |
| ebazpena | 800(RGB)×1280 , WXGA |
| bistaratzeko modua | ADS, Normally Black, Transmissive |
| eremu aktiboa | 129×206.4 mm |
| eskema | 133.4×213.85 mm |
| azalera | |
| beiraren sakonera | 0.25+0.25 mm |
| transmisibitatea | 5.6% (Typ.)(with Polarizer) |
| kontraste-erlazioa | 800:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (8-bit) |
| erantzun denbora | 30 (Typ.)(Tr+Td) |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| gidariaren ic | Built-in NT51017 |
| seinale interfazea | MIPI (4 data lanes), 40 pins |
| aplikazio | PAD |
| BP096WX1-100 | BOE | 9.6 | 800×1280 |
| BP096WX7-100 | BOE | 9.6 | 800×1280 |
| TV096WXM-NS0 | BOE | 9.6 | 800×1280 |
| BP070HD1-100 | BOE | 7.0 | 720×1280 |
| HJ101NA-02A | Innolux | 10.1 | 1280×800 |
| HSD101PWW1-B00-C11 | HannStar | 10.1 | 1280×800 |
| HV121WX5-110 | HYDIS | 12.1 | 1280×800 |
| LD070WU2-SH01 | LG Display | 7.0 | 1200×1920 |
| LD101WX2-SLP1 | LG Display | 10.1 | 1280×800 |
| LP079QX1-SP0V | LG Display | 7.9 | 1536×2048 |
| LTL089CL02-002 | Samsung | 8.9 | 1920×1200 |
| LTL106AL01-002 | Samsung | 10.6 | 1366×768 |
| VVX10F004B00 | Panasonic | 10.1 | 1920×1200 |
