| PartZenbakia | BP096WX1-100 |
| Marka | BOE |
| Tamaina | 9.6 |
| Aplikazio | PAD |
| Ebazpena | 800×1280 |
| Konposizioa | LCM |
| Distira | 350 |
| CR | 800:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | MIPI |
| panel marka | BOE |
| panel eredua | BP096WX1-100 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 9.6 inch |
| ebazpena | 800(RGB)×1280 , WXGA |
| bistaratzeko modua | ADS, Normally Black, Transmissive |
| eremu aktiboa | 129×206.4 mm |
| eskema | 136.8×217.1×4.2 mm |
| azalera | Antiglare (Haze 3.1%) |
| distira | 350 cd/m² (Typ.) |
| kontraste-erlazioa | 800:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (8-bit), CIE193150% |
| erantzun denbora | 20/20 (Typ.)(Tr/Td) |
| ikuspegi angelua | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 7S4PWLEDWithout Driver |
| seinale interfazea | MIPI (4 data lanes), 45 pins |
| sarrerako tentsioa | 1.8/3.7V (Typ.)(VDD/VDDI) |
| aplikazio | PAD |
