| PartZenbakia | TV096WXM-NS0 |
| Marka | BOE |
| Tamaina | 9.6 |
| Aplikazio | PAD |
| Ebazpena | 800×1280 |
| Konposizioa | LCM |
| Distira | 450 |
| CR | 900:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | MIPI |
| panel marka | BOE |
| panel eredua | TV096WXM-NS0 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 9.6 inch |
| ebazpena | 800(RGB)×1280 , WXGA |
| bistaratzeko modua | ADS, Normally Black, Transmissive |
| eremu aktiboa | 129×206.4 mm |
| eskema | 136.7×217×4.65 mm |
| azalera | Hard coating, Antireflection |
| distira | 450 cd/m² (Typ.) |
| kontraste-erlazioa | 900:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (8-bit), CIE193147% |
| erantzun denbora | |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 7S4PWLEDWithout Driver |
| seinale interfazea | MIPI (4 data lanes), 34 pins |
| sarrerako tentsioa | 3.3V (Typ.) |
| aplikazio | PAD |
| B101EAN01.7 | AUO | 10.1 | 1280×800 |
| B101XAN01.3 | AUO | 10.1 | 1366×768 |
| BP101WX1-100 | BOE | 10.1 | 1280×800 |
| CLAA101WJ06 | CPT | 10.1 | 1366×768 |
| HE070IA-04M | Innolux | 7.0 | 800×1280 |
| HSD101PWW1-H00 | HannStar | 10.1 | 1280×800 |
| HX121WX1-100 | HYDIS | 12.1 | 1280×800 |
| LP097QX1-SPA2 | LG Display | 9.7 | 2048×1536 |
| LT070ME05000 | JDI | 7.0 | 1200×1920 |
| YXD090TN02-40NM01 | SEBO | 9.0 | 1280×800 |
