AT070TN92 V.3

AT070TN92 V.3
AT070TN92 V.3
AT070TN92 V.3
AT070TN92 V.3 thumb AT070TN92 V.3 thumb AT070TN92 V.3 thumb
Marka
Innolux
Tamaina
7.0
Aplikazio
MP4
Ebazpena
800×480
Konposizioa
LCM
Distira
250
CR
500:1
Koloreak
262K/16.7M
Atzeko argia
WLED
Interfazea
TTL
In Stock
6457
Zehaztapenak

PartZenbakia AT070TN92 V.3
MarkaInnolux
Tamaina7.0
AplikazioMP4
Ebazpena800×480
KonposizioaLCM
Distira250
CR500:1
Koloreak262K/16.7M
Atzeko argiaWLED
InterfazeaTTL
panel markaCHIMEI INNOLUX
panel ereduaAT070TN92 V.3
panel mota a-Si TFT-LCD , LCM
panelaren tamaina7.0 inch
ebazpena800(RGB)×480 , WVGA
bistaratzeko moduaTN, Normally White, Transmissive
eremu aktiboa154.08×85.92 mm
eskema164.9×100×3.65 mm
azaleraAntiglare
distira250 cd/m² (Typ.)
kontraste-erlazioa500:1 (Typ.)
bistaratzeko koloreak262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193150%
erantzun denbora10/15 (Typ.)(Tr/Td)
ikuspegi angelua70/70/50/70 (Typ.)(CR≥10)(L/R/U/D)
maiztasuna60Hz
lanpara mota3S9PWLEDWithout Driver
seinale interfazeaParallel RGB (1 ch, 6/8-bit), 50 pins
sarrerako tentsioa3.3/10.4/16.0/-7.0V (Typ.)(DVDD/AVDD/VGH/VGL)
aplikazioMP4
