| PartZenbakia | TM080XPH01 |
| Marka | Tianma |
| Tamaina | 8.0 |
| Aplikazio | MP4 |
| Ebazpena | 1280×768 |
| Konposizioa | CELL |
| Distira | 0 |
| CR | 400:1 |
| Koloreak | 262K |
| Atzeko argia | No B/L |
| Interfazea | Mini LVDS |
| panel marka | TIANMA |
| panel eredua | TM080XPH01 |
| panel mota | a-Si TFT-LCD , CELL |
| panelaren tamaina | 8.0 inch |
| ebazpena | 1280(RGB)×768 , WXGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 173.76×104.256 mm |
| eskema | 181×112.8×3.05 mm |
| azalera | |
| beiraren sakonera | 0.50+0.50 mm |
| kontraste-erlazioa | 400:1 (Typ.) |
| bistaratzeko koloreak | 262K (6-bit), CIE193150% |
| erantzun denbora | 25/25 (Typ.)(Tr/Td) |
| ikuspegi angelua | 70/70/65/65 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| seinale interfazea | Mini LVDS, 40 pins |
| sarrerako tentsioa | 3.3/12.5/22.0/-7.0V (Typ.)(VDD/AVDD/VGH/VGL) |
| aplikazio | MP4 |
