| PartZenbakia | TX06D15VM1EAA |
| Marka | KOE |
| Tamaina | 2.2 |
| Aplikazio | MPH |
| Ebazpena | 176×220 |
| Konposizioa | LCM |
| Distira | 60 |
| CR | 40:1 |
| Koloreak | 65K/262K |
| Atzeko argia | WLED |
| Interfazea | TTL |
| panel marka | HITACHI |
| panel eredua | TX06D15VM1EAA |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 2.2 inch |
| ebazpena | 176(RGB)×220 , QCIF+ |
| bistaratzeko modua | IPS, Normally Black, Transflective |
| eremu aktiboa | 34.848×43.56 mm |
| eskema | 41.85×56 mm |
| azalera | |
| distira | 60 cd/m² (Typ.) |
| kontraste-erlazioa | 40:1 (Typ.)(Transmissive)15:1 (Typ.)(Reflective) |
| bistaratzeko koloreak | 65K/262K |
| erantzun denbora | 35 (Typ.)(Tr+Td) |
| ikuspegi angelua | |
| lanpara mota | 1S3PWLED |
| seinale interfazea | Parallel RGB + SPI, 45 pins |
| sarrerako tentsioa | 2.8/2.8V (Typ.)(VCC/VCI) |
| rohs: | |
| aplikazio | MPH |
| AM-240320-022F | Other | 2.2 | 240×320 |
| COM22H2P16ULC | ORTUSTECH | 2.2 | 240×320 |
| CT022TN15 | Innolux | 2.2 | 176×220 |
| DLC0220KZG | Other | 2.2 | 320×320 |
| LMS220GF08 | Samsung | 2.2 | 240×320 |
| LTS220QC-F0J | Samsung | 2.2 | 176×220 |
| TM022GDH11 | Tianma | 2.2 | 176×220 |
| TM022HDH31 | Tianma | 2.2 | 240×320 |
| TM022HDHT1-05 | Tianma | 2.2 | 240×320 |
| TX06D15VM1EAA | KOE | 2.2 | 176×220 |
| AMEJ006 | Samsung | 2.8 | 240×400 |
| CLAF040LE21 AX | CPT | 4.0 | 480×800 |
| HSD060FMW1-C00 | HannStar | 6.0 | 540×960 |
| LH480HX1-SD01 | LG Display | 4.8 | 480×1024 |
| LMS220GF08 | Samsung | 2.2 | 240×320 |
| LMS241GF31 | Samsung | 2.4 | 240×320 |
| LMS320HF46 | Samsung | 3.2 | 240×432 |
| LT031MDZ4000 | JDI | 3.1 | 720×720 |
| TM028LDZ09 | Tianma | 2.8 | 240×400 |
| TM032PDZ17 | Tianma | 3.2 | 320×480 |
