| PartZenbakia | LH480HX1-SD01 |
| Marka | LG Display |
| Tamaina | 4.8 |
| Aplikazio | MPH |
| Ebazpena | 480×1024 |
| Konposizioa | LCM |
| Distira | 500 |
| CR | 700:1 |
| Koloreak | 16.2M |
| Atzeko argia | WLED |
| Interfazea | TTL |
| panel marka | LG Display |
| panel eredua | LH480HX1-SD01 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 4.8 inch |
| ebazpena | 480(RGB)×1024 |
| bistaratzeko modua | IPS, Normally Black, Transmissive |
| eremu aktiboa | 51.84×110.592 mm |
| eskema | 57.64×121.45 mm |
| azalera | |
| distira | 500 cd/m² (Typ.) |
| kontraste-erlazioa | 700:1 (Typ.) |
| bistaratzeko koloreak | 16.2M (6-bit + Dithering), CIE193168% |
| erantzun denbora | 35 (Typ.)(Tr+Td) |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 5S2PWLEDWithout Driver |
| seinale interfazea | Parallel RGB (1 ch, 8-bit) + SPI, 60 pins |
| sarrerako tentsioa | 1.8/2.8V (Typ.)(IOVCC/VCC) |
| aplikazio | MPH |
