| PartZenbakia | NL10276BC30-39 |
| Marka | NLT |
| Tamaina | 15.0 |
| Aplikazio | IA |
| Ebazpena | 1024×768 |
| Konposizioa | LCM |
| Distira | 270 |
| CR | 900:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | NEC |
| panel eredua | NL10276BC30-39 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 15.0 inch |
| ebazpena | 1024(RGB)×768 , XGA |
| bistaratzeko modua | UA-SFT, Normally Black, Transmissive |
| eremu aktiboa | 304.128×228.096 mm |
| eskema | 326.5×253.5×12.2 mm |
| azalera | Antiglare, Hard coating (3H) |
| distira | 270 cd/m² (Typ.) |
| kontraste-erlazioa | 900:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (8-bit), CIE193172% |
| erantzun denbora | 14/11 (Typ.)(Tr/Td) |
| ikuspegi angelua | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 6 stringsWLEDWithout Driver |
| seinale interfazea | LVDS (1 ch, 8-bit), 20 pins |
| sarrerako tentsioa | 3.3V (Typ.) |
| aplikazio | IA |
| NL10276AC30-07 | NLT | 15.0 | 1024×768 |
| NL10276AC30-42C | NLT | 15.0 | 1024×768 |
| NL10276BC12-02 | NLT | 6.3 | 1024×768 |
| NL10276BC20-37 | NLT | 10.4 | 1024×768 |
| NL10276BC24-13 | NLT | 12.1 | 1024×768 |
| NL10276BC28-21A | NLT | 14.1 | 1024×768 |
| NL10276BC30-17 | NLT | 15.0 | 1024×768 |
| NL10276BC30-18L | NLT | 15.0 | 1024×768 |
| NL10276BC30-33D | NLT | 15.0 | 1024×768 |
| NL10276BC30-39 | NLT | 15.0 | 1024×768 |
| DLC1040ABG-2 | Other | 10.4 | 800×600 |
| G133I1-L02 | Innolux | 13.3 | 1280×800 |
| G150XTN06.1 | AUO | 15.0 | 1024×768 |
| HLD0909-020010 | Hosiden | 9.0 | 640×480 |
| LM-GK53-22NTX | SANYO | 13.6 | 1024×768 |
| LM7MS623 | SHARP | 6.5 | 640×240 |
| LQ150X1LGB1 | SHARP | 15.0 | 1024×768 |
| LTA090B230F | TOSHIBA | 9.0 | 536×328 |
| NL8048AC19-13 | NLT | 7.0 | 800×480 |
| TX18D11VM1CAA | KOE | 7.0 | 800×480 |
