| PartZenbakia | TX18D11VM1CAA |
| Marka | KOE |
| Tamaina | 7.0 |
| Aplikazio | IA |
| Ebazpena | 800×480 |
| Konposizioa | LCM |
| Distira | 400 |
| CR | 200:1 |
| Koloreak | 262K |
| Atzeko argia | CCFL |
| Interfazea | TTL |
| panel marka | HITACHI |
| panel eredua | TX18D11VM1CAA |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 7.0 inch |
| ebazpena | 800(RGB)×480 , WVGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 152.4×91.44 mm |
| eskema | 165×106×10.5 mm |
| azalera | |
| distira | 400 cd/m² (Typ.) |
| kontraste-erlazioa | 200:1 (Typ.) |
| bistaratzeko koloreak | 262K (6-bit) |
| erantzun denbora | 30/20 (Typ.)(Tr/Td) |
| ikuspegi angelua | 65/65/45/60 (Typ.)(CR≥5)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 1 pcsCCFLWithout Driver |
| seinale interfazea | CMOS (1 ch, 6-bit), 40 pins |
| sarrerako tentsioa | 3.3V (Typ.)(VDD) |
| rohs: | |
| aplikazio | IA |
| A070PAN01.0 | AUO | 7.0 | 900×1440 |
| CLAA069JA11CW | CPT | 7.0 | 480×234 |
| CLAA070JA1BCW | CPT | 7.0 | 480×234 |
| DLC0700CZG-6 | Other | 7.0 | 800×480 |
| LA070WV5-SL01 | LG Display | 7.0 | 800×480 |
| LB070WQ7-TD02 | LG Display | 7.0 | 480×234 |
| LB070WV6-TD06 | LG Display | 7.0 | 800×480 |
| PM070WL1 | E Ink | 7.0 | 800×480 |
| TM070RBH10 | Tianma | 7.0 | 800×480 |
| TX18D11VM1CAA | KOE | 7.0 | 800×480 |
| AA104XG12 | Mitsubishi | 10.4 | 1024×768 |
| FX050700DSCWDG12 | Data Image | 5.7 | |
| G158ETN01.0 | AUO | 15.8 | |
| LQ064V3DG01 | SHARP | 6.4 | 640×480 |
| M190EG01 V3 | AUO | 19.0 | 1280×1024 |
| NL8060AC26-04 | NLT | 10.4 | 800×600 |
| NL8060BC21-11C | NLT | 8.4 | 800×600 |
| PD104SLD | E Ink | 10.4 | 800×600 |
| T78AAVGTF0 | Other | 5.7 | 320×240 |
| UMSH-8065MD-11T | Other | 3.5 | 320×240 |
