| PartZenbakia | NL10276BC16-01 |
| Marka | NLT |
| Tamaina | 8.4 |
| Aplikazio | IA |
| Ebazpena | 1024×768 |
| Konposizioa | LCM |
| Distira | 400 |
| CR | 400:1 |
| Koloreak | 262K/16.7M |
| Atzeko argia | CCFL |
| Interfazea | LVDS |
| panel marka | NEC |
| panel eredua | NL10276BC16-01 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 8.4 inch |
| ebazpena | 1024(RGB)×768 , XGA |
| bistaratzeko modua | UA-SFT, Normally Black, Transmissive |
| eremu aktiboa | 170.496×127.872 mm |
| eskema | 200×152 mm |
| azalera | Antiglare, Hard coating (3H) |
| distira | 400 cd/m² (Typ.) |
| kontraste-erlazioa | 400:1 (Typ.) |
| bistaratzeko koloreak | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193172% |
| erantzun denbora | 13/12 (Typ.)(Tr/Td) |
| ikuspegi angelua | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 4 pcsCCFLWithout Driver |
| seinale interfazea | LVDS (1 ch, 6/8-bit), 20 pins |
| sarrerako tentsioa | 3.3V (Typ.) |
| aplikazio | IA |
| NL10276AC20-03 | NLT | 10.4 | 1024×768 |
| NL10276AC30-04R | NLT | 15.0 | 1024×768 |
| NL10276AC30-07 | NLT | 15.0 | 1024×768 |
| NL10276BC12-02 | NLT | 6.3 | 1024×768 |
| NL10276BC16-06 | NLT | 8.4 | 1024×768 |
| NL10276BC20-04 | NLT | 10.4 | 1024×768 |
| NL10276BC20-18 | NLT | 10.4 | 1024×768 |
| NL10276BC24-13 | NLT | 12.1 | 1024×768 |
| NL10276BC30-33D | NLT | 15.0 | 1024×768 |
| NL10276BC30-39 | NLT | 15.0 | 1024×768 |
| AA084VC05 | Mitsubishi | 8.4 | 640×480 |
| DLC1500AMG-1 | Other | 15.0 | 1024×768 |
| G215HVN01.0 S11 | AUO | 21.5 | 1920×1080 |
| LQ10DH15 | SHARP | 10.4 | 640×480 |
| LQ121S1LG44 | SHARP | 12.1 | 800×600 |
| LQ121S1LG61 | SHARP | 12.1 | 800×600 |
| LTD121C33S | TOSHIBA | 12.1 | 800×600 |
| NL10276BC30-38B | NLT | 15.0 | 1024×768 |
| NL6448AC33-29 | NLT | 10.4 | 640×480 |
| NL6448BC33-20 | NLT | 10.4 | 640×480 |
