| PartZenbakia | NL10276AC30-04R |
| Marka | NLT |
| Tamaina | 15.0 |
| Aplikazio | DMPC |
| Ebazpena | 1024×768 |
| Konposizioa | LCM |
| Distira | 200 |
| CR | 200:1 |
| Koloreak | 262K |
| Atzeko argia | CCFL |
| Interfazea | LVDS |
| panel marka | NEC |
| panel eredua | NL10276AC30-04R |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 15.0 inch |
| ebazpena | 1024(RGB)×768 , XGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 304.128×228.096 mm |
| eskema | 350×265×20.5 mm |
| azalera | Antireflection |
| distira | 200 cd/m² (Typ.) |
| kontraste-erlazioa | 200:1 (Typ.) |
| bistaratzeko koloreak | 262K (6-bit), CIE193140% |
| erantzun denbora | 15/40 (Typ.)(Tr/Td) |
| ikuspegi angelua | 60/60/40/50 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 2 pcsCCFLEmbedded (Inverter) |
| seinale interfazea | LVDS (1 ch, 6-bit), 20 pins |
| sarrerako tentsioa | 5.0V (Typ.) |
| aplikazio | DMPC |
