| PartZenbakia | LTL106HL01-001 |
| Marka | Samsung |
| Tamaina | 10.6 |
| Aplikazio | PAD |
| Ebazpena | 1920×1080 |
| Konposizioa | LCM |
| Distira | 400 |
| CR | 800:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | SAMSUNG |
| panel eredua | LTL106HL01-001 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 10.6 inch |
| ebazpena | 1920(RGB)×1080 , FHD |
| bistaratzeko modua | PLS, Normally Black, Transmissive |
| eremu aktiboa | 234.72×132.03 mm |
| eskema | 246.52×149.02×5.2 mm |
| azalera | Glare (Haze 0%), Hard coating (2H) |
| distira | 400 cd/m² (Typ.) |
| kontraste-erlazioa | 800:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (8-bit), CIE193150% |
| erantzun denbora | 16 (Typ.)(Tr+Td) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 9S4PWLEDEmbedded (LED Driver) |
| seinale interfazea | LVDS (2 ch, 8-bit), 51 pins |
| sarrerako tentsioa | 3.3V (Typ.) |
| aplikazio | PAD |
| LQ106K1LA01C | SHARP | 10.6 | 1280×768 |
| LQ106K1LA02 | SHARP | 10.6 | 1280×768 |
| LQ106K1LA05 | SHARP | 10.6 | 1280×768 |
| LTD106EXXF | TOSHIBA | 10.6 | 1280×768 |
| LTL106AL01-001 | Samsung | 10.6 | 1366×768 |
| LTL106AL01-002 | Samsung | 10.6 | 1366×768 |
| LTL106HL01-001 | Samsung | 10.6 | 1920×1080 |
| LTL106HL02-001 | Samsung | 10.6 | 1920×1080 |
| LTN106W2-L01 | Samsung | 10.6 | 1280×768 |
| NL12876AC18-03 | NLT | 10.6 | 1280×768 |
| B080EAN01.1 | AUO | 8.0 | 800×1280 |
| B101EAN02.2 | AUO | 10.1 | 800×1280 |
| BP070WS1-400 | BOE | 7.0 | 1024×600 |
| CLAA101FP05 XG | CPT | 10.1 | 1920×1200 |
| EJ101IA-01G | Innolux | 10.1 | 1280×800 |
| HSD101PWW2-A01 | HannStar | 10.1 | 1280×800 |
| HV121WX4-120 | HYDIS | 12.1 | 1280×800 |
| LP079X01-SMA2 | LG Display | 7.9 | 768×1024 |
| LQ101K1LY02 | SHARP | 10.1 | 1280×800 |
| TFTMD070021 | JDI | 7.0 | 1200×1920 |
