| PartZenbakia | B101EAN02.2 |
| Marka | AUO |
| Tamaina | 10.1 |
| Aplikazio | PAD |
| Ebazpena | 800×1280 |
| Konposizioa | LCM |
| Distira | 350 |
| CR | 1000:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | AUO |
| panel eredua | B101EAN02.2 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 10.1 inch |
| ebazpena | 800(RGB)×1280 , WXGA |
| bistaratzeko modua | AHVA, Normally Black, Transmissive |
| eremu aktiboa | 135.36×216.576 mm |
| eskema | 142×228.5 mm |
| azalera | Glare (Haze 0%), Antireflection |
| distira | 350 cd/m² (Typ.) |
| kontraste-erlazioa | 1000:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (8-bit), CIE193160% |
| erantzun denbora | 30 (Typ.)(Tr+Td) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | WLEDWithout Driver |
| seinale interfazea | LVDS (1 ch, 8-bit), 39 pins |
| sarrerako tentsioa | 3.3V (Typ.) |
| aplikazio | PAD |
