| PartZenbakia | LTL106HL02-001 |
| Marka | Samsung |
| Tamaina | 10.6 |
| Aplikazio | PAD |
| Ebazpena | 1920×1080 |
| Konposizioa | LCM |
| Distira | 400 |
| CR | 800:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | SAMSUNG |
| panel eredua | LTL106HL02-001 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 10.6 inch |
| ebazpena | 1920(RGB)×1080 , FHD |
| bistaratzeko modua | PLS, Normally Black, Transmissive |
| eremu aktiboa | 234.72×132.03 mm |
| eskema | 244.92×145.06×4.56 mm |
| azalera | Glare (Haze 0%), Hard coating (2H) |
| distira | 400 cd/m² (Typ.) |
| kontraste-erlazioa | 800:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (8-bit), CIE193150% |
| erantzun denbora | 16 (Typ.)(Tr+Td) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 6S6PWLEDEmbedded (LED Driver) |
| seinale interfazea | LVDS (2 ch, 8-bit), 60 pins |
| sarrerako tentsioa | 3.3V (Typ.) |
| aplikazio | PAD |
| CLAA080WQ05 | CPT | 8.0 | 800×1280 |
| CLAA101WJ01 | CPT | 10.1 | 1366×768 |
| HX104X01-210 | HYDIS | 10.4 | 1024×768 |
| LP097X02-SLQ1 | LG Display | 9.7 | 1024×768 |
| LP101WX2-SLP1 | LG Display | 10.1 | 1280×800 |
| LTL106HL02-001 | Samsung | 10.6 | 1920×1080 |
| LTL120QL01-001 | Samsung | 12.0 | 2160×1440 |
| N101BCG-L21 | Innolux | 10.1 | 1366×768 |
| TV080X0M-NS0 | BOE | 8.0 | 768×1024 |
| YX101GL-01A | SEBO | 10.1 | 1280×800 |
