| PartZenbakia | LS055R1SC01 |
| Marka | SHARP |
| Tamaina | 5.5 |
| Aplikazio | MPH |
| Ebazpena | 1440×2560 |
| Konposizioa | LCM |
| Distira | 480 |
| CR | 1300:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | MIPI |
| panel marka | SHARP |
| panel eredua | LS055R1SC01 |
| panel mota | CG-Silicon , LCM |
| panelaren tamaina | 5.5 inch |
| ebazpena | 1440(RGB)×2560 , Quad-HD |
| bistaratzeko modua | New Mode2, Normally Black, Transmissive |
| eremu aktiboa | 68.04×120.96 mm |
| eskema | 70.87×128.45×1.45 mm |
| azalera | Hard coating (3H) |
| distira | 480 cd/m² (Typ.) |
| kontraste-erlazioa | 1300:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (8-bit), CIE193170% |
| erantzun denbora | 35 (Max.)(Tr+Td) |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | WLEDWithout Driver |
| seinale interfazea | MIPI (2 ch, 4 data lanes), 45 pins |
| sarrerako tentsioa | 1.8/5.75/-5.75V (Typ.)(IOVDD/AVDD+/AVDD-) |
| aplikazio | MPH |
