| PartZenbakia | TD035SHED1 |
| Marka | TPO |
| Tamaina | 3.5 |
| Aplikazio | MPH |
| Ebazpena | 480×640 |
| Konposizioa | LCM |
| Distira | 170 |
| CR | 200:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | TTL |
| panel marka | TPO |
| panel eredua | TD035SHED1 |
| panel mota | LTPS TFT-LCD , LCM |
| panelaren tamaina | 3.5 inch |
| ebazpena | 480(RGB)×640 , VGA |
| bistaratzeko modua | TN, Normally White, Transflective |
| eremu aktiboa | 53.28×71.04 mm |
| eskema | 64×85 mm |
| azalera | |
| distira | 170 cd/m² (Typ.) |
| kontraste-erlazioa | 200:1 (Typ.)(Transmissive)8:1 (Typ.)(Reflective) |
| bistaratzeko koloreak | 262K (6-bit), CIE193137% |
| erantzun denbora | 35 (Typ.)(Tr+Td) |
| ikuspegi angelua | 80/80/80/70 (Typ.)(CR≥10)(L/R/U/D) |
| lanpara mota | 6S1PWLEDWithout Driver |
| seinale interfazea | Parallel RGB (1 ch, 6-bit) + SPI, 51 pins |
| sarrerako tentsioa | 3.0/3.0V (Typ.)(VDC/VDDIO) |
| aplikazio | MPH |
