| PartZenbakia | H546DLB01.1 |
| Marka | AUO |
| Tamaina | 5.5 |
| Aplikazio | MPH |
| Ebazpena | 1080×1920 |
| Konposizioa | OLED |
| Distira | 350 |
| CR | 10000:1 |
| Koloreak | 16.7M |
| Atzeko argia | self |
| Interfazea | MIPI |
| panel marka | AUO |
| panel eredua | H546DLB01.1 |
| panel mota | AM-OLED , OLED |
| panelaren tamaina | 5.5 inch |
| ebazpena | 1080(RGB)×1920 , FHD |
| eremu aktiboa | 68.04×120.96 mm |
| eskema | 70.84×128.01 mm |
| azalera | Hard coating (3H) |
| distira | 350 cd/m² (Typ.) |
| kontraste-erlazioa | 10000 : 1 (Min.) |
| bistaratzeko koloreak | 16.7M (8-bit), CIE1931103% |
| ikuspegi angelua | 80/80/80/80 (Min.)(CR≥1600)(L/R/U/D) |
| gidariaren ic | COG Built-in RM69070 |
| seinale interfazea | MIPI (2 data lanes), 40 pins |
| sarrerako tentsioa | 1.8/3.0/4.6/7.6V (Typ.)(IOVCC/VCI/OVDD/AVDD) |
| aplikazio | MPH |
| BT055FWM-N00 | BOE | 5.5 | 480×854 |
| CLAN055WA41 3XB | CPT | 5.5 | 720×1280 |
| H546DAN01.2 | AUO | 5.5 | 1080×1920 |
| H546DLB01.1 | AUO | 5.5 | 1080×1920 |
| LH550WF4-SD01 | LG Display | 5.5 | 1080×1920 |
| LS055R1SC01 | SHARP | 5.5 | 1440×2560 |
| NL3224AC35-01 | NLT | 5.5 | 320×240 |
| NL3224AC35-05 | NLT | 5.5 | 320×240 |
| PJ055IA-14C | Innolux | 5.5 | 1080×1920 |
| TM055XDHP10 | Tianma | 5.5 | 540×960 |
| BS055FHE-N30-6Q00 | BOE | 5.5 | 1080×1920 |
| BT043NHME601 | BOE | 4.3 | 360×600 |
| CLAN055WA41 3XB | CPT | 5.5 | 720×1280 |
| DLC0220BMG | Other | 2.2 | 240×320 |
| DLC0350SZG | Other | 3.5 | 480×640 |
| H495TAN01.1 | AUO | 5.0 | 720×1280 |
| LS063R1SX01 | SHARP | 6.3 | 1440×2560 |
| LT042MDV5000 | JDI | 4.2 | 768×1280 |
| LTP283QV-F04 | Samsung | 2.8 | 240×320 |
| TX10D121VM0AAA | JDI | 4.0 | 480×800 |
