| PartZenbakia | TP241MC01G |
| Marka | Neoview Kolon |
| Tamaina | 2.4 |
| Aplikazio | MPH |
| Ebazpena | 240×320 |
| Konposizioa | OLED |
| Distira | 140 |
| CR | |
| Koloreak | 16.7M |
| Atzeko argia | self |
| Interfazea | CPU/SPI |
| panel marka | Neoview Kolon |
| panel eredua | TP241MC01G |
| panel mota | TOLED , OLED |
| panelaren tamaina | 2.4 inch |
| ebazpena | 240(RGB)×320 , QVGA |
| eremu aktiboa | 36.72×48.96 mm |
| eskema | 42.92×59.46×1.5 mm |
| azalera | |
| distira | 140 cd/m² (Typ.) |
| kontraste-erlazioa | |
| bistaratzeko koloreak | 16.7M (8-bit) |
| ikuspegi angelua | |
| gidariaren ic | Built-in DA8620 |
| seinale interfazea | 8-bit 8080 parallel, SPI, 39 pins |
| sarrerako tentsioa | 18.0V (Typ.) |
| rohs: | |
| aplikazio | MPH |
