| PartZenbakia | E555HBM2 |
| Marka | EDO |
| Tamaina | 5.5 |
| Aplikazio | MPH |
| Ebazpena | 720×1280 |
| Konposizioa | OLED |
| Distira | 300 |
| CR | 3000:1 |
| Koloreak | 16.7M |
| Atzeko argia | self |
| Interfazea | MIPI |
| panel marka | EDO |
| panel eredua | E555HBM2 |
| panel mota | AM-OLED , OLED |
| panelaren tamaina | 5.5 inch |
| ebazpena | 720(RGB)×1280 , WXGA |
| eremu aktiboa | 69.12×122.88 mm |
| eskema | 72.8×131.2 mm |
| azalera | |
| distira | 300 cd/m² (Typ.) |
| kontraste-erlazioa | 3000 : 1 (Min.) |
| bistaratzeko koloreak | 16.7M (8-bit), CIE1931105% |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥200)(L/R/U/D) |
| gidariaren ic | COG Built-in SH1386 |
| seinale interfazea | MIPI (4 data lanes), 30 pins |
| sarrerako tentsioa | 3.3/4.6/6.1/-3.5V (Typ.)(VCI/VELVDD/VSP/VELVSS) |
| aplikazio | MPH |
