| PartZenbakia | LS030Q7DH01 |
| Marka | SHARP |
| Tamaina | 3.0 |
| Aplikazio | MPH |
| Ebazpena | 240×320 |
| Konposizioa | LCM |
| Distira | 100 |
| CR | 70:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | TTL |
| panel marka | SHARP |
| panel eredua | LS030Q7DH01 |
| panel mota | CG-Silicon , LCM |
| panelaren tamaina | 3.0 inch |
| ebazpena | 240(RGB)×320 , QVGA |
| bistaratzeko modua | TN, Normally White, Transflective |
| eremu aktiboa | 45.72×60.96 mm |
| eskema | 54.5×75 mm |
| azalera | Hard coating (3H) |
| distira | 100 cd/m² (Typ.) |
| kontraste-erlazioa | 70:1 (Typ.)(Transmissive)2.5:1 (Typ.)(Reflective) |
| bistaratzeko koloreak | 262K (6-bit), CIE193165% |
| erantzun denbora | 30/50 (Typ.)(Tr/Td) |
| ikuspegi angelua | 40/40/40/40 (Typ.)(CR≥2)(L/R/U/D) |
| lanpara mota | 5S1PWLEDWithout Driver |
| seinale interfazea | Parallel RGB (1 ch, 6-bit), 51 pins |
| sarrerako tentsioa | 3.3/5.0/8.0/-4.0/-8.0V (Typ.)(VSHD/VSHA/VDD/VSSD/GVSS) |
| aplikazio | MPH |
