| PartZenbakia | CM546B2-001 |
| Marka | CSOT |
| Tamaina | 5.5 |
| Aplikazio | Mobile Phone |
| Ebazpena | 1080×1920 |
| Konposizioa | LTPS TFT-LCD, CELL |
| Distira | |
| CR | 1500:1 |
| Koloreak | 16.7M |
| Atzeko argia | No |
| Interfazea | |
| panel marka | CSOT |
| panel eredua | CM546B2-001 |
| panelaren tamaina | 5.5" |
| panel mota | LTPS TFT-LCD, CELL |
| ebazpena | 1080(RGB)×1920, FHD, 403PPI |
| pixel formatua | RGB Vertical Stripe |
| bistaratzeko eremua | 68.04(W)×120.96(H) mm |
| bezela irekidura | - |
| eskema tamaina | 69.44(W)×126.81(H) ×0.45(D) mm |
| azalera | With Polarizer |
| distira | 0 cd/m² |
| kontraste-erlazioa | 1500:1 (Typ.) (TM) |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥10) |
| bistaratzeko modua | FFS, Normally Black, Transmissive |
| ikuspegirik onena | Symmetry |
| erantzun denbora | 35 (Typ.)(Tr+Td) |
| beiraren sakonera | 0.15+0.15 mm |
| transmisibitatea | 4.69% (Typ.)(with APCF) |
| bistaratzeko koloreak | 16.7M 80% NTSC |
| lanpara mota | No B/L |
| maiztasuna | - |
| pantaila taktila | In-Cell Touch |
| gidariaren ic | COG Built-in TD4310 |
| panelaren pisua | TBD |
| aplikazio | Mobile Phone |
| ingurunea | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
