| PartZenbakia | NL3224AC35-10 |
| Marka | NLT |
| Tamaina | 5.5 |
| Aplikazio | IA |
| Ebazpena | 320×240 |
| Konposizioa | LCM |
| Distira | 250 |
| CR | 85:1 |
| Koloreak | Full color |
| Atzeko argia | CCFL |
| Interfazea | Analog |
| panel marka | NEC |
| panel eredua | NL3224AC35-10 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 5.5 inch |
| ebazpena | 320(RGB)×240 , QVGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 111.36×83.52 mm |
| eskema | 134×110 mm |
| azalera | Glare (Haze 0%), Hard coating (2H) |
| distira | 250 cd/m² (Typ.) |
| kontraste-erlazioa | 85:1 (Typ.) |
| bistaratzeko koloreak | Full color , CIE193150% |
| erantzun denbora | 16/44 (Typ.)(Tr/Td) |
| ikuspegi angelua | 50/50/25/25 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 1 pcsCCFLEmbedded (Inverter) |
| seinale interfazea | Analog RGB, 24 pins |
| sarrerako tentsioa | 12.0V (Typ.) |
| aplikazio | IA |
| BS055FHE-N30-6Q00 | BOE | 5.5 | 1080×1920 |
| E555HBM2 | EDO | 5.5 | 720×1280 |
| LPM055A138A | JDI | 5.5 | 1440×2560 |
| NL3224AC35-01 | NLT | 5.5 | 320×240 |
| NL3224AC35-05 | NLT | 5.5 | 320×240 |
| NL3224AC35-06 | NLT | 5.5 | 320×240 |
| NL3224AC35-10 | NLT | 5.5 | 320×240 |
| NL3224BC35-20 | NLT | 5.5 | 320×240 |
| NL3224BC35-20R | NLT | 5.5 | 320×240 |
| NL3224BC35-22 | NLT | 5.5 | 320×240 |
| AA104SH02 | Mitsubishi | 10.4 | 800×600 |
| AA104VH02 | Mitsubishi | 10.4 | 640×480 |
| G150XTN06.4 | AUO | 15.0 | 1024×768 |
| KCS6448HSTT-X3 | Kyocera | 10.4 | 640×480 |
| LQ084V1DG22 | SHARP | 8.4 | 640×480 |
| SP14Q001 | KOE | 5.7 | 320×240 |
| SX25S004 | KOE | 10.0 | 800×600 |
| TM084SDHG02 | Tianma | 8.4 | 800×600 |
| TX16D18VM2CAB | KOE | 6.2 | 800×300 |
| TX26D02VM1CAA | KOE | 10.4 | 640×480 |
