| PartZenbakia | TM055JDHP71 |
| Marka | Tianma |
| Tamaina | 5.5 |
| Aplikazio | MPH |
| Ebazpena | 720×1280 |
| Konposizioa | LCM |
| Distira | 450 |
| CR | 900:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | MIPI |
| panel marka | TIANMA |
| panel eredua | TM055JDHP71 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 5.5 inch |
| ebazpena | 720(RGB)×1280 , WXGA |
| bistaratzeko modua | SFT, Normally Black, Transmissive |
| eremu aktiboa | 68.04×120.96 mm |
| eskema | 71.14×130.76 mm |
| azalera | |
| distira | 450 cd/m² (Typ.) |
| kontraste-erlazioa | 900:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (8-bit), CIE193172% |
| erantzun denbora | 35 (Max.)(Tr+Td) |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 6S2PWLEDWithout Driver |
| seinale interfazea | MIPI (4 data lanes), 30 pins |
| sarrerako tentsioa | 1.8/5.5/-5.5V (Typ.)(IOVCC/VSP/VSN) |
| aplikazio | MPH |
