| PartZenbakia | CLAA101WH13LE |
| Marka | CPT |
| Tamaina | 10.1 |
| Aplikazio | PAD |
| Ebazpena | 1280×800 |
| Konposizioa | LCM |
| Distira | 250 |
| CR | 600:1 |
| Koloreak | 262K/16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | CPT |
| panel eredua | CLAA101WH13LE |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 10.1 inch |
| ebazpena | 1280(RGB)×800 , WXGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 216.96×135.6 mm |
| eskema | 229.76×149.4×4.96 mm |
| azalera | Hard coating (3H) |
| distira | 250 cd/m² (Typ.) |
| kontraste-erlazioa | 600:1 (Typ.) |
| bistaratzeko koloreak | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193150% |
| erantzun denbora | 30 (Typ.)(Tr+Td) |
| ikuspegi angelua | 80/80/60/80 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 3S12PWLEDWithout Driver |
| seinale interfazea | LVDS (1 ch, 8-bit), 40 pins |
| sarrerako tentsioa | 3.3/11.0/21.0/-6V (Typ.)(DVDD/AVDD/VGH/VGL) |
| aplikazio | PAD |
| CLAA101FP01 | CPT | 10.1 | 1920×1200 |
| CLAA101FP01 XG | CPT | 10.1 | 1920×1200 |
| CLAA101FP05 XG | CPT | 10.1 | 1920×1200 |
| CLAA101NC01CW | CPT | 10.1 | 1024×600 |
| CLAA101WB03 | CPT | 10.1 | 1366×768 |
| CLAA101WJ01 | CPT | 10.1 | 1366×768 |
| CLAA102NA1BCN | CPT | 10.2 | 1024×600 |
| CLAA102NA2CCN | CPT | 10.2 | 1024×600 |
| CLAA104XA01CW | CPT | 10.4 | 1024×768 |
| CLAA104XA12BW | CPT | 10.4 | 1024×768 |
| B101EAN02.2 | AUO | 10.1 | 800×1280 |
| B101EVT03.1 | AUO | 10.1 | 1280×800 |
| HQ097QX1-IPS | Other | 9.7 | 2048×1536 |
| HV070WS1-105 | HYDIS | 7.0 | 1024×600 |
| HX121WX1-111 | HYDIS | 12.1 | 1280×800 |
| LP101WH4-SLAF | LG Display | 10.1 | 1366×768 |
| LTL106HL01-001 | Samsung | 10.6 | 1920×1080 |
| LTN097XL01-A01 | Samsung | 9.7 | 1024×768 |
| LTN097XL01-A02 | Samsung | 9.7 | 1024×768 |
| M101NWWB R6 | IVO | 10.1 | 1280×800 |
