| PartZenbakia | LTN097XL01-A01 |
| Marka | Samsung |
| Tamaina | 9.7 |
| Aplikazio | PAD |
| Ebazpena | 1024×768 |
| Konposizioa | LCM |
| Distira | 390 |
| CR | 900:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | SAMSUNG |
| panel eredua | LTN097XL01-A01 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 9.7 inch |
| ebazpena | 1024(RGB)×768 , XGA |
| bistaratzeko modua | PLS, Normally Black, Transmissive |
| eremu aktiboa | 196.608×147.456 mm |
| eskema | 210×166.2 mm |
| azalera | Glare (Haze 0%), Hard coating (3H) |
| distira | 390 cd/m² (Typ.) |
| kontraste-erlazioa | 900:1 (Typ.) |
| bistaratzeko koloreak | 262K (6-bit), CIE193152% |
| erantzun denbora | 30 (Typ.)(Tr+Td) |
| ikuspegi angelua | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | WLEDWithout Driver |
| seinale interfazea | LVDS (1 ch, 6-bit), 30 pins |
| sarrerako tentsioa | 3.3V (Typ.) |
| aplikazio | PAD |
| BI097XN02 V.Y | Innolux | 9.7 | 1024×768 |
| LP097QX1-SPAV | LG Display | 9.7 | 2048×1536 |
| LP097QX3-SPAV | LG Display | 9.7 | 1536×2048 |
| LP097X02-SLN1 | LG Display | 9.7 | 1024×768 |
| LQ097L1JY01A | SHARP | 9.7 | 2048×1536 |
| LTL097QL01-A01 | Samsung | 9.7 | 2048×1536 |
| LTN097XL01-A01 | Samsung | 9.7 | 1024×768 |
| LTN097XL01-A02 | Samsung | 9.7 | 1024×768 |
| LTN097XL02-A01 | Samsung | 9.7 | 1024×768 |
| TM097TDH01 | Tianma | 9.7 | 1024×768 |
| B101EVT03.1 | AUO | 10.1 | 1280×800 |
| B101EW04 V0 | AUO | 10.1 | 1280×800 |
| HX121WX1-111 | HYDIS | 12.1 | 1280×800 |
| LP097QX1-SPA1 | LG Display | 9.7 | 2048×1536 |
| LTL101AL06-801 | Samsung | 10.1 | 1280×800 |
| M101NWWB R8 | IVO | 10.1 | 1280×800 |
| N080ICE-GB0 Rev.C1 | Innolux | 8.0 | 800×1280 |
| N080ICE-GB1 | Innolux | 8.0 | 800×1280 |
| TFTMD070021 | JDI | 7.0 | 1200×1920 |
| TV097X0M-NS0 | BOE | 9.7 | 768×1024 |
