| PartZenbakia | BP070WX1-300 |
| Marka | BOE |
| Tamaina | 7.0 |
| Aplikazio | PAD |
| Ebazpena | 800×1280 |
| Konposizioa | LCM |
| Distira | |
| CR | |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | MIPI |
| panel marka | BOE |
| panel eredua | BP070WX1-300 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 7.0 inch |
| ebazpena | 800(RGB)×1280 , WXGA |
| bistaratzeko modua | AFFS, Normally Black, Transmissive |
| eremu aktiboa | 94.2×150.72 mm |
| eskema | 99.7×160.93×3.8 mm |
| azalera | Hard coating (3H), Antireflection |
| distira | |
| kontraste-erlazioa | |
| bistaratzeko koloreak | 16.7M (6-bit + Hi-FRC), CIE193150% |
| erantzun denbora | 30 (Typ.)(Tr+Td) |
| ikuspegi angelua | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 5S4PWLEDWithout Driver |
| seinale interfazea | MIPI, 34 pins |
| sarrerako tentsioa | 1.8/3.3V (Typ.)(IOVCC/VDD) |
| aplikazio | PAD |
