| PartZenbakia | B101UAN01.E |
| Marka | AUO |
| Tamaina | 10.1 |
| Aplikazio | PAD |
| Ebazpena | 1920×1200 |
| Konposizioa | LCM |
| Distira | 400 |
| CR | 800:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | MIPI |
| panel marka | AUO |
| panel eredua | B101UAN01.E |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 10.1 inch |
| ebazpena | 1920(RGB)×1200 , WUXGA |
| bistaratzeko modua | AHVA, Normally Black, Transmissive |
| eremu aktiboa | 216.81×135.5 mm |
| eskema | 227.72×148.66×4.4 mm |
| azalera | Glare (Haze 0%) |
| distira | 400 cd/m² (Typ.) |
| kontraste-erlazioa | 800:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (6-bit + Hi-FRC), CIE193150% |
| erantzun denbora | 25 (Typ.)(Tr+Td) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 6 stringsWLEDWithout Driver |
| seinale interfazea | MIPI (4 data lanes), 39 pins |
| sarrerako tentsioa | 3.3V (Typ.) |
| aplikazio | PAD |
