| PartZenbakia | TPF0702002N |
| Marka | JDI |
| Tamaina | 7.0 |
| Aplikazio | PAD |
| Ebazpena | 1200×1920 |
| Konposizioa | CELL |
| Distira | 0 |
| CR | 1200:1 |
| Koloreak | 16.7M |
| Atzeko argia | No B/L |
| Interfazea | MIPI |
| panel marka | JDI |
| panel eredua | TPF0702002N |
| panel mota | LTPS TFT-LCD , CELL |
| panelaren tamaina | 7.0 inch |
| ebazpena | 1200(RGB)×1920 , WUXGA |
| bistaratzeko modua | Normally Black, Transmissive |
| eremu aktiboa | 94.5×151.2 mm |
| eskema | 97.3×159.4×0.77 mm |
| azalera | Hard coating |
| beiraren sakonera | 0.25+0.25 mm |
| transmisibitatea | 3.8% (Typ.)(with Polarizer) |
| kontraste-erlazioa | 1200:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (8-bit), CIE193172% |
| erantzun denbora | 25 (Typ.)(Tr+Td) |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| seinale interfazea | MIPI, 40 pins |
| sarrerako tentsioa | 1.8/5.5/-5.5V (Typ.)(IOVCC/VSP/VSN) |
| aplikazio | PAD |
