| PartZenbakia | AT080TN64 |
| Marka | Innolux |
| Tamaina | 8.0 |
| Aplikazio | CNS |
| Ebazpena | 800×480 |
| Konposizioa | LCM |
| Distira | 450 |
| CR | 500:1 |
| Koloreak | 262K/16.2M |
| Atzeko argia | WLED |
| Interfazea | TTL |
| panel marka | INNOLUX |
| panel eredua | AT080TN64 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 8.0 inch |
| ebazpena | 800(RGB)×480 , WVGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 176.64×99.36 mm |
| eskema | 192.8×116.9 mm |
| azalera | Antiglare |
| distira | 450 cd/m² (Typ.) |
| kontraste-erlazioa | 500:1 (Typ.) |
| bistaratzeko koloreak | 262K/16.2M (6-bit / 6-bit + Dithering), CIE193150% |
| erantzun denbora | 10/15 (Typ.)(Tr/Td) |
| ikuspegi angelua | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 3S12PWLEDWithout Driver |
| seinale interfazea | Parallel RGB (1 ch, 6/8-bit), 50 pins |
| sarrerako tentsioa | 3.3/10.4/16.0/-7.0V (Typ.)(DVDD/AVDD/VGH/VGL) |
| aplikazio | CNS |
