| PartZenbakia | TM050LDZ00 |
| Marka | Tianma |
| Tamaina | 5.0 |
| Aplikazio | CNS |
| Ebazpena | 240×400 |
| Konposizioa | LCM |
| Distira | 400 |
| CR | 200:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | TTL |
| panel marka | TIANMA |
| panel eredua | TM050LDZ00 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 5.0 inch |
| ebazpena | 240(RGB)×400 , WQVGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 65.16×108.6 mm |
| eskema | 76.3×123.4×12.9 mm |
| azalera | Antiglare |
| distira | 400 cd/m² (Min.) |
| kontraste-erlazioa | 200:1 (Min.) |
| bistaratzeko koloreak | 262K (6-bit), CIE193170% |
| erantzun denbora | 40 (Max.)(Tr+Td) |
| ikuspegi angelua | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| lanpara mota | 1S10PWLEDWithout Driver |
| seinale interfazea | Parallel RGB (1 ch, 6/8-bit) + SPI, 40 pins |
| sarrerako tentsioa | 3.3V (Typ.) |
| aplikazio | CNS |
