| PartZenbakia | AM-1024600K7TMQW-T04H |
| Marka | AMPIRE |
| Tamaina | 7.0 |
| Aplikazio | Industrial |
| Ebazpena | 1024×600 |
| Konposizioa | a-Si TFT-LCD , LCM |
| Distira | |
| CR | 700:1 |
| Koloreak | 262K |
| Atzeko argia | 8S3P |
| Interfazea | |
| panel marka | AMPIRE |
| panelaren tamaina | 7.0" |
| ebazpena | 1024(RGB)×600, WSVGA, 169PPI |
| bistaratzeko eremua | 153.6(W)×90(H) mm |
| eskema tamaina | 165.5(W)×104.44(H) ×10.81(D) mm |
| distira | 850 cd/m² (Typ.) |
| ikuspegi angelua | 75/75/70/75 (Typ.)(CR≥10) |
| ikuspegirik onena | 6 o'clock |
| bistaratzeko koloreak | 262K |
| maiztasuna | 60Hz |
| pisua | TBD |
| panel eredua | AM-1024600K7TMQW-T04H |
| panel mota | a-Si TFT-LCD , LCM |
| pixel formatua | RGB Vertical Stripe |
| bezela irekidura | - |
| azalera | - |
| kontraste-erlazioa | 700:1 (Typ.) (TM) |
| bistaratzeko modua | TN, Normally White, Transmissive |
| erantzun denbora | 20/20 (Typ.)(Tr/Td) |
| lanpara mota | 8S3P WLED , 50K hours , With LED Driver |
| pantaila taktila | PCAP |
| aplikazio | Industrial |
