| PartZenbakia | A070FW03 V7 |
| Marka | AUO |
| Tamaina | 7.0 |
| Aplikazio | CNS |
| Ebazpena | 480×234 |
| Konposizioa | LCM |
| Distira | 280 |
| CR | 400:1 |
| Koloreak | |
| Atzeko argia | WLED |
| Interfazea | Analog |
| panel marka | AUO |
| panel eredua | A070FW03 V7 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 7.0 inch |
| ebazpena | 480(RGB)×234 |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 154.08×86.58 mm |
| eskema | 164.9×100 mm |
| azalera | Antiglare (Haze 25%) |
| distira | 280 cd/m² (Typ.) |
| kontraste-erlazioa | 400:1 (Typ.) |
| bistaratzeko koloreak | |
| erantzun denbora | 12/18 (Typ.)(Tr/Td) |
| ikuspegi angelua | 65/65/40/65 (Typ.)(CR≥10)(L/R/U/D) |
| lanpara mota | 3S7PWLEDWithout Driver |
| seinale interfazea | TFT Specific Analog RGB, 26 pins |
| sarrerako tentsioa | 5/5/15/-10V (Typ.)(VCC/AVDD/VGH/VGL) |
| rohs: | |
| aplikazio | CNS |
