| PartZenbakia | TX23D86VM0BAA |
| Marka | KOE |
| Tamaina | 9.0 |
| Aplikazio | IA |
| Ebazpena | 1280×768 |
| Konposizioa | LCM |
| Distira | 350 |
| CR | 1000:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | HITACHI |
| panel eredua | TX23D86VM0BAA |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 9.0 inch |
| ebazpena | 1280(RGB)×768 , WXGA |
| bistaratzeko modua | IPS NP, Normally Black, Transmissive |
| eremu aktiboa | 193.92×116.352 mm |
| eskema | 216×142 mm |
| azalera | |
| distira | 350 cd/m² (Typ.) |
| kontraste-erlazioa | 1000:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (6-bit + Hi-FRC), CIE193172% |
| erantzun denbora | 22 (Typ.)(Tr+Td) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | WLEDEmbedded (LED Driver) |
| seinale interfazea | LVDS (1 ch, 8-bit), 30 pins |
| sarrerako tentsioa | 3.3V (Typ.) |
| aplikazio | IA |
| C090EAN01.1 | AUO | 9.0 | 1280×720 |
| CLAA090LC41CW | CPT | 9.0 | 800×480 |
| CLAA090NA06CW | CPT | 9.0 | 1024×600 |
| ED090NA-01H | Innolux | 9.0 | 1280×800 |
| HSD090ICW1-A00 | HannStar | 9.0 | 640×234 |
| NL192108AC10-01D | NLT | 9.0 | 1920×1080 |
| NL8048BC24-14NH | NLT | 9.0 | 800×480 |
| TX23D12VM0CAA | KOE | 9.0 | 800×480 |
| TX23D85VM0BAA | KOE | 9.0 | 1280×768 |
| TX23D86VM0BAA | KOE | 9.0 | 1280×768 |
| G084SN03 V2 | AUO | 8.4 | 800×600 |
| G240UAN01.0 | AUO | 24.0 | 1920×1200 |
| M150GNN2 R1 | IVO | 15.0 | 1024×768 |
| NL10276BC30-18L | NLT | 15.0 | 1024×768 |
| NL6448BC26-08D | NLT | 8.4 | 640×480 |
| SP10Q010 | KOE | 3.8 | 320×240 |
| TM24064BBCWVBYD | Tianma | 5.2 | 240×64 |
| TX23D86VM0BAA | KOE | 9.0 | 1280×768 |
| UG-2832TLBGG01 | WiseChip | 1.0 | 128×32 |
| UG-2864KSYMG01 | WiseChip | 1.54 | 128×64 |
