| PartZenbakia | HSD090ICW1-A00 |
| Marka | HannStar |
| Tamaina | 9.0 |
| Aplikazio | DPF |
| Ebazpena | 640×234 |
| Konposizioa | LCM |
| Distira | 250 |
| CR | 500:1 |
| Koloreak | |
| Atzeko argia | WLED |
| Interfazea | Analog |
| panel marka | HannStar |
| panel eredua | HSD090ICW1-A00 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 9.0 inch |
| ebazpena | 640(RGB)×234 |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 197.76×111.735 mm |
| eskema | 210.7×126.4×4.25 mm |
| azalera | |
| distira | 250 cd/m² (Typ.) |
| kontraste-erlazioa | 500:1 (Typ.) |
| bistaratzeko koloreak | , CIE193145% |
| erantzun denbora | 25 (Typ.)(Tr+Td) |
| ikuspegi angelua | 70/70/65/65 (Typ.)(CR≥10)(L/R/U/D) |
| lanpara mota | 3S8PWLEDWithout Driver |
| seinale interfazea | TFT Specific Analog RGB, 26 pins |
| sarrerako tentsioa | 3.3/5/15/-10V (Typ.)(DVDD/AVDD/VGH/VGL) |
| aplikazio | DPF |
| AA090ME01 | Mitsubishi | 9.0 | 800×480 |
| AT090TN23 | Innolux | 9.0 | 1280×800 |
| ED090NA-01H | Innolux | 9.0 | 1280×800 |
| HSD090ICW1-A00 | HannStar | 9.0 | 640×234 |
| HSD090IDW1-A00 | HannStar | 9.0 | 800×480 |
| LQ090Y3DG01A | SHARP | 9.0 | 800×480 |
| LTA090B400F | TOSHIBA | 9.0 | 800×480 |
| NL8048BC24-09D | NLT | 9.0 | 800×480 |
| NL8048BC24-12 | NLT | 9.0 | 800×480 |
| TX23D12VM0CAA | KOE | 9.0 | 800×480 |
| A080SN03 V0 | AUO | 8.0 | 800×600 |
| CLAA080LA0BCW | CPT | 8.0 | 800×480 |
| HSD070IDW1-A20 | HannStar | 7.0 | 800×480 |
| HSD070ISN1-D00 | HannStar | 7.0 | 800×600 |
| HSD100IFW1-C01 | HannStar | 10.1 | 1024×600 |
| HSD101PFW2-B00 | HannStar | 10.1 | 1024×600 |
| LQ085Y3DG12 | SHARP | 8.5 | 800×480 |
| LQ090Y3DG01 | SHARP | 9.0 | 800×480 |
| LTE700WQ-F05 | Samsung | 7.0 | 480×234 |
| TR-LM7WR3PS | Panasonic | 7.0 | 480×234 |
