| PartZenbakia | TM101JDHG33 |
| Marka | TIANMA |
| Tamaina | 10.1 |
| Aplikazio | Industrial Medical I |
| Ebazpena | 1280×800 |
| Konposizioa | a-Si TFT-LCD , LCM |
| Distira | |
| CR | 700:1 |
| Koloreak | 262K/16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| marka | TIANMA |
| diagonalaren tamaina | 10.1 inch |
| pixel formatua | 1280(RGB)×800 [WXGA] 149PPI |
| eremu aktiboa | 216.96(H)×135.6(V) mm |
| bezela eremua | 219.96(H)×138.6(V) mm |
| luminantzia | 900 cd/m² (Typ.) |
| ikusi norabidea | Symmetry |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| euskarria kolorea | 262K/16.7M 50% NTSC |
| pisua | 280g (Typ.) |
| fotograma-tasa | 60Hz |
| interfaze mota | LVDS (1 ch, 6/8-bit) , 40 pins Connector |
| energia hornidura | 3.3V (Typ.) |
| ingurunea | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -40 ~ 80 °C |
| eredua | TM101JDHG33 |
| mota | a-Si TFT-LCD , LCM |
| konfigurazioa | RGB Vertical Stripe |
| eskema dim. | 229.8(H)×149(V) ×9.6(D) mm |
| tratamendua | Hard coating |
| kontraste-erlazioa | 700:1 (Typ.) (TM) |
| erantzun denbora | 25 (Typ.)(Tr+Td) |
| funtzionamendu modua | SFT, Normally Black, Transmissive |
| argi iturria | WLED , 40K hours , With LED Driver |
| entzat diseinatua | Industrial Medical Imaging Outdoor High Brightness |
| ukipen-panela | Without |
| B101AW02 V0 | AUO | 10.1 | 1024×600 |
| B101AW06 V1 HW0A | AUO | 10.1 | 1024×600 |
| CLAA101NB03A | CPT | 10.1 | 1024×600 |
| CLAA101WH12 LE | CPT | 10.1 | 1280×800 |
| LP101WH1-TLA2 | LG Display | 10.1 | 1366×768 |
| LTL101AL02-T01 | Samsung | 10.1 | 1280×800 |
| LTN101NT02-W05 | Samsung | 10.1 | 1024×600 |
| TM101DDHG01 | Tianma | 10.1 | 1024×600 |
| TM101DDHG03 | Tianma | 10.1 | 1024×600 |
| TM101JDHP01 | Tianma | 10.1 | 1280×800 |
