| PartZenbakia | TM080VDSP01 |
| Marka | Tianma |
| Tamaina | 8.0 |
| Aplikazio | PAD |
| Ebazpena | 1200×1920 |
| Konposizioa | LCM |
| Distira | 390 |
| CR | 900:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | MIPI |
| panel marka | TIANMA |
| panel eredua | TM080VDSP01 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 8.0 inch |
| ebazpena | 1200(RGB)×1920 , WUXGA |
| bistaratzeko modua | SFT, Normally Black, Transmissive |
| eremu aktiboa | 107.64×172.224 mm |
| eskema | 114.6×184.1×2.3 mm |
| azalera | |
| distira | 390 cd/m² (Typ.) |
| kontraste-erlazioa | 900:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (8-bit), CIE193160% |
| erantzun denbora | 25 (Typ.)(Tr+Td) |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 7S3PWLEDWithout Driver |
| seinale interfazea | MIPI (4 data lanes), 31 pins |
| sarrerako tentsioa | 3.3/10.0/18.0/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| aplikazio | PAD |
