| PartZenbakia | TM047XDZP02 |
| Marka | Tianma |
| Tamaina | 4.7 |
| Aplikazio | MPH |
| Ebazpena | 540×960 |
| Konposizioa | LCM |
| Distira | 400 |
| CR | 1000:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | MIPI |
| panel marka | TIANMA |
| panel eredua | TM047XDZP02 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 4.7 inch |
| ebazpena | 540(RGB)×960 , qHD |
| bistaratzeko modua | SFT, Normally Black, Transmissive |
| eremu aktiboa | 58.32×103.68 mm |
| eskema | 62.72×113.53×1.78 mm |
| azalera | |
| distira | 400 cd/m² (Typ.) |
| kontraste-erlazioa | 1000:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (8-bit), CIE193170% |
| erantzun denbora | 25 (Typ.)(Tr+Td) |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 5S2PWLEDWithout Driver |
| seinale interfazea | MIPI (2 data lanes), 24 pins |
| sarrerako tentsioa | (1.8/2.8)/2.8V (Typ.)(IOVCC/VCC) |
| aplikazio | MPH |
