| PartZenbakia | LS047T1SC02 |
| Marka | SHARP |
| Tamaina | 4.7 |
| Aplikazio | MPH |
| Ebazpena | 1080×1920 |
| Konposizioa | LCM |
| Distira | 470 |
| CR | 1000:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | MIPI |
| panel marka | SHARP |
| panel eredua | LS047T1SC02 |
| panel mota | CG-Silicon , LCM |
| panelaren tamaina | 4.7 inch |
| ebazpena | 1080(RGB)×1920 , FHD |
| bistaratzeko modua | New Mode2, Normally Black, Transmissive |
| eremu aktiboa | 57.996×103.104 mm |
| eskema | 60.4×112.2×1.48 mm |
| azalera | |
| distira | 470 cd/m² (Typ.) |
| kontraste-erlazioa | 1000:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (8-bit), CIE193171% |
| erantzun denbora | 35 (Max.)(Tr+Td) |
| ikuspegi angelua | |
| maiztasuna | 60Hz |
| lanpara mota | 2 stringsWLEDWithout Driver |
| seinale interfazea | MIPI (4 data lanes), 31 pins |
| sarrerako tentsioa | 5.0/-5.0/1.8V (Typ.)(AVDD/AVEE-/IOVCC) |
| aplikazio | MPH |
| DX12D100VM0EAA | JDI | 4.7 | 720×1280 |
| G321EV5R000 | SII | 4.7 | 320×240 |
| KCG047QV1AA-A21 | Kyocera | 4.7 | 320×240 |
| KCG047QV1AA-A210 | Kyocera | 4.7 | 320×240 |
| LH470WX6-SJ11 | LG Display | 4.7 | 750×1334 |
| LM32K10 | SHARP | 4.7 | 320×240 |
| LS047T1SC01K | SHARP | 4.7 | 1080×1920 |
| LS047T1SC02 | SHARP | 4.7 | 1080×1920 |
| PG320240C | Other | 4.7 | 320×240 |
| TM047NBH03 | Tianma | 4.7 | 480×272 |
| 43WVF2A | SII | 4.3 | 480×800 |
| ACX399CMP-7 | SONY | 2.9 | 640×360 |
| BTL282440-310L | BOE | 2.8 | 240×400 |
| CLAN050LL31 1XG | CPT | 5.0 | 480×800 |
| DX08D11VM0AAA | KOE | 3.0 | 480×800 |
| LH400WS1-SD03 | LG Display | 4.0 | 640×1136 |
| LQ043Y1DX03D | SHARP | 4.3 | 480×800 |
| LS040T3SW01 | SHARP | 4.0 | 540×960 |
| LS050T1SX10 | SHARP | 5.0 | 1080×1920 |
| TM022HDHT1-00 | Tianma | 2.2 | 240×320 |
