| PartZenbakia | TM022GBH01 |
| Marka | Tianma |
| Tamaina | 2.2 |
| Aplikazio | MPH |
| Ebazpena | 176×220 |
| Konposizioa | LCM |
| Distira | 250 |
| CR | 350:1 |
| Koloreak | 65K/262K |
| Atzeko argia | WLED |
| Interfazea | CPU |
| panel marka | TIANMA |
| panel eredua | TM022GBH01 1 Compatible model |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 2.2 inch |
| ebazpena | 176(RGB)×220 , QCIF+ |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 34.848×43.56 mm |
| eskema | 41.7×56.16 mm |
| azalera | Clear, Hard coating (3H) |
| distira | 250 cd/m² (Typ.) |
| kontraste-erlazioa | 350:1 (Typ.) |
| bistaratzeko koloreak | 65K/262K , CIE193160% |
| erantzun denbora | 25 (Typ.)(Tr+Td) |
| ikuspegi angelua | 45/45/40/20 (Typ.)(CR≥10)(L/R/U/D) |
| lanpara mota | 1S3PWLEDWithout Driver |
| seinale interfazea | CPU, 36 pins |
| sarrerako tentsioa | 2.8V (Typ.)(VDD) |
| aplikazio | MPH |
