| PartZenbakia | TD035STED4 |
| Marka | TPO |
| Tamaina | 3.5 |
| Aplikazio | PDA |
| Ebazpena | 240×320 |
| Konposizioa | LCM |
| Distira | 115 |
| CR | 100:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | TTL |
| panel marka | Toppoly |
| panel eredua | TD035STED4 |
| panel mota | LTPS TFT-LCD , LCM |
| panelaren tamaina | 3.5 inch |
| ebazpena | 240(RGB)×320 , QVGA |
| bistaratzeko modua | TN, Normally White, Transflective |
| eremu aktiboa | 53.28×71.04 mm |
| eskema | 64.3×87.1×4.8 mm |
| azalera | |
| distira | 115 cd/m² (Typ.) |
| kontraste-erlazioa | 100:1 (Typ.)(Transmissive)15:1 (Typ.)(Reflective) |
| bistaratzeko koloreak | 262K (6-bit), CIE193136% |
| erantzun denbora | 35 (Typ.)(Tr+Td) |
| ikuspegi angelua | 60/60/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 4S1PWLEDWithout Driver |
| seinale interfazea | Parallel RGB (1 ch, 6-bit) + SPI, 61 pins |
| sarrerako tentsioa | 2.8/5.0/10/-5.5V (Typ.)(VDD/AVDD/VGH/WEE) |
| aplikazio | PDA |
| ACX502BMU-7 | SONY | 3.5 | 240×320 |
| LS037V7DD05 | SHARP | 3.7 | 480×640 |
| NL2432HC22-22B | NLT | 3.5 | 240×320 |
| NL2432HC22-23B | NLT | 3.5 | 240×320 |
| NL2432HC22-40J | NLT | 3.5 | 240×320 |
| NL2432HC22-41B | NLT | 3.5 | 240×320 |
| NL2432HC22-41K | NLT | 3.5 | 240×320 |
| TD035STED4 | TPO | 3.5 | 240×320 |
| TD035STED7 | TPO | 3.5 | 240×320 |
| TX09D23VM1CAA | KOE | 3.5 | 240×320 |
