| PartZenbakia | ACX502BMU-7 |
| Marka | SONY |
| Tamaina | 3.5 |
| Aplikazio | PDA |
| Ebazpena | 240×320 |
| Konposizioa | LCM |
| Distira | 70 |
| CR | 80:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | TTL |
| panel marka | SONY |
| panel eredua | ACX502BMU-7 |
| panel mota | LTPS TFT-LCD , LCM |
| panelaren tamaina | 3.5 inch |
| ebazpena | 240(RGB)×320 , QVGA |
| bistaratzeko modua | TN, Normally White, Transflective |
| azalera | Hard coating (3H) |
| distira | 70 cd/m² (Typ.) |
| kontraste-erlazioa | 80:1 (Typ.)(Transmissive)7:1 (Typ.)(Reflective) |
| bistaratzeko koloreak | 262K (6-bit) |
| erantzun denbora | |
| ikuspegi angelua | |
| maiztasuna | 60Hz |
| lanpara mota | 6 pcsWLEDWithout Driver |
| seinale interfazea | Parallel RGB (1 ch, 6-bit) |
| sarrerako tentsioa | 3.0/5.0V (Typ.)(VDD1/VDD2) |
| rohs: | |
| aplikazio | PDA |
| 35HVE0H | SII | 3.5 | 320×480 |
| A035CN02 V1 | AUO | 3.5 | 480×234 |
| A035QN02 VE | AUO | 3.5 | 320×240 |
| ACX502BMU-7 | SONY | 3.5 | 240×320 |
| C035QVN01.0 | AUO | 3.5 | 240×320 |
| LQ035Q3DG01 | SHARP | 3.5 | 320×240 |
| LTV350QV-F02 | Samsung | 3.5 | 320×240 |
| LTV350QV-F04 | Samsung | 3.5 | 320×240 |
| NL2432HC22-41B | NLT | 3.5 | 240×320 |
| PT035TN01 V.3 | Innolux | 3.5 | 320×240 |
| LQ035Q7DH02 | SHARP | 3.5 | 240×320 |
| LTM035A776B | TOSHIBA | 3.5 | 240×320 |
| LTP500GV-F01 | Samsung | 5.0 | 480×640 |
| NL2432HC22-25E | NLT | 3.5 | 240×320 |
| NL4864HL11-01B | NLT | 3.5 | 480×640 |
| TD035STEB2 | TPO | 3.5 | 240×320 |
| TD035STED4 | TPO | 3.5 | 240×320 |
| TD035STED7 | TPO | 3.5 | 240×320 |
| TM038QV-67A03 | SANYO | 3.8 | 320×240 |
| TX09D23VM1CAA | KOE | 3.5 | 240×320 |
