| PartZenbakia | NL2432HC22-40J |
| Marka | NLT |
| Tamaina | 3.5 |
| Aplikazio | PDA |
| Ebazpena | 240×320 |
| Konposizioa | LCM |
| Distira | 220 |
| CR | 150:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | TTL |
| panel marka | NEC |
| panel eredua | NL2432HC22-40J |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 3.5 inch |
| ebazpena | 240(RGB)×320 , QVGA |
| bistaratzeko modua | TN, Normally White, Transflective |
| eremu aktiboa | 53.64×71.52 mm |
| eskema | 63.5×85×3.2 mm |
| azalera | Clear, Hard coating (3H) |
| distira | 220 cd/m² (Typ.) |
| kontraste-erlazioa | 150:1 (Typ.)(Transmissive)15:1 (Typ.)(Reflective) |
| bistaratzeko koloreak | 262K (6-bit), CIE193140% |
| erantzun denbora | 7/23 (Typ.)(Tr/Td) |
| ikuspegi angelua | 35/35/35/35 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 5S1PWLEDWithout Driver |
| seinale interfazea | CMOS (1 ch, 6-bit) + SPI, 45 pins |
| sarrerako tentsioa | 3.0V (Typ.) |
| aplikazio | PDA |
