| PartZenbakia | PA050XSG |
| Marka | E Ink |
| Tamaina | 5.0 |
| Aplikazio | CNS |
| Ebazpena | 320×234 |
| Konposizioa | LCM |
| Distira | 400 |
| CR | 400:1 |
| Koloreak | |
| Atzeko argia | CCFL |
| Interfazea | Analog |
| panel marka | PVI |
| panel eredua | PA050XSG |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 5.0 inch |
| ebazpena | 320(RGB)×234 |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 102.72×74.53 mm |
| eskema | 119.3×91.4×7.8 mm |
| azalera | Antiglare |
| distira | 400 cd/m² (Typ.) |
| kontraste-erlazioa | 400:1 (Typ.) |
| bistaratzeko koloreak | |
| erantzun denbora | 15/30 (Typ.)(Tr/Td) |
| ikuspegi angelua | 70/70/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| lanpara mota | 1 pcsCCFLWithout Driver |
| seinale interfazea | TFT Specific Analog RGB, 30 pins |
| sarrerako tentsioa | 3.3/3.3/5.0/17.0/-12.0V (Typ.)(VCC/VDD1/VDD2/VGH/VGL) |
| aplikazio | CNS |
