| PartZenbakia | PM070WT2 |
| Marka | E Ink |
| Tamaina | 7.0 |
| Aplikazio | CNS |
| Ebazpena | 800×480 |
| Konposizioa | LCM |
| Distira | 400 |
| CR | 400:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | TTL |
| panel marka | PVI |
| panel eredua | PM070WT2 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 7.0 inch |
| ebazpena | 800(RGB)×480 , WVGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 152.4×91.44 mm |
| eskema | 166.3×105.3×11 mm |
| azalera | Antiglare |
| distira | 400 cd/m² (Typ.) |
| kontraste-erlazioa | 400:1 (Typ.) |
| bistaratzeko koloreak | 262K (6-bit) |
| erantzun denbora | 15/25 (Typ.)(Tr/Td) |
| ikuspegi angelua | 60/60/40/55 (Typ.)(CR≥10)(L/R/U/D) |
| lanpara mota | 3S11PWLEDWithout Driver |
| seinale interfazea | TTL (1 ch, 6-bit), 30 pins |
| sarrerako tentsioa | 3.3V (Typ.)(VCC) |
| rohs: | |
| aplikazio | CNS |
